Organic Membrane

Ceramic membrane technology and organic membrane technology can be used in combination. Organic membrane can follow ceramic membrane. We have organic membranes with wide range of pore sizes to different applications, from removing salt to filtering large particulates. JIUWU company can help you design the suitable membrane process.
Organic Membrane
  • Organic membranes
  • Organic membranes
  • Organic membranes


PDF Download

OVER VIEW OF ORGANIC MEMBRANES

The application of membrane technology is food, dairy, pharmaceutical, biotechnology and starch, and sweetener industries. Cross-flow membrane filtration is the technology of choice for many industrial processes. For example, it can be used in beer membrane filtration. The advantage is that the separation or concentration of products without the application of heat.

Benefits compared with other methods of separation include:

  • Accurate separation of multiple streams;
  • Reduced risk of damage especially for heat-sensitive products;
  • No loss of nutritional value or clinical efficacy
  • Reduced energy consumption;
  • Reduced waste disposal costs
  • Higher yields
  • Greater flexibility for new product development

WHAT JIUWU OFFER

1. Spiral Membranes

Spiral membrane is cross-flow membrane filtration, with pore sizes (reverse osmosis, nanofiltration, ultrafiltration, and microfiltration). Spiral membranes have a compact layout and high membrane area per element making them ideal for high-flow applications with minimal or no suspended solids. They have the advantage of the low component and operating costs.

The applications of spiral membrane include food and dairy separation, electrocoat paint recovery, brackish water treatment, water softening and organics removal. The sanitary spirals are widely used in dairy, food and pharmaceutical industries for clarification, concentration, and purification of valuable ingredients, meeting quality standards without compromising yield. The membrane filtration of milk greatly improves its quality. In addition, spiral membrane offers the highest packing density and most economical solution.


2. Hollow-Fiber Membranes

We offer a variety of ultrafiltration and microfiltration hollow-fiber products. The operate cost-effectively is low energy for both small and large filtration volumes. Applications of hollow-fiber membrane include municipal water and wastewater treatment, industrial biotechnology, and food and beverage production.

Ceramic membrane technology and organic membrane technology can be used in combination. Organic membrane can follow the ceramic membrane. We have organic membranes with a wide range of pore sizes to different applications, from removing salt to filtering large particulates. JIUWU company can help you design the suitable membrane process.

Membrane type Ultrafiltration Nanofil tration Reverse Osmosis
Module type
Module type
Hollow Fiber          Tubular              Plate                  Spiral
MWC0 0.05um-1KD 0.1KD-1KD
0perating pressure 0.05-2. 7Mpa 0.5-4. 2Mpa 1.0-6.9Mpa
Application Remove suspended-solids and reduce SS
Remove impurities, such as proteins,
polysaccharides and pigments
Remove bacteria, heat source
Reduce COD/ B0C.
Dehydration concentration
Desalting purification/ salt purification
Dehydration and concentration
Decolorization
Solvent recovery
Desalting
Dehydration, concentration, enrichment
Remove C0D/BOD
Case Enzyme such as phytase
Antibiotics such as penicillin
Amino acids such as L- phenylalanine
Soybean peptide, oligosaccharides, etc.
Dairy, juice, etc.
MBR: Industrial wastewater treatment MBR
Pretreatment for reverse osmosis
Antibiotics such as streptomycin
L-lactic acid, vitamins, etc.
Fluorescent whitening agent,
reactive dye
Dairy, oligosaccharides, etc.
Chinese medicine, natural product concentration
Industrial wastewater treatment
softened water preparation
Preparation of  pure water in
pharmaceutical factories, food factories
Power plant boiler water preparation
Electronics factory ultrapure water preparation
Traditional Chinese medicine,
natural product extraction
Antibiotics, amino acids
Industrial wastewater treatment
